Description
Pre-Owned Stalfors Lasermax Shaft Driven 52CDC Unwinder
The Stalfors Lasermax Unwind 52 is based on the printing industry standard of a center-shaft drive mechanism making it the safest, most accurate, flexible and reliable roll-feed system available. The starting point of any pre- and post-processing system, it feeds a roll of paper, up to 20.5″ wide and 52″ in diameter, into the printer. It uses all standard roll core sizes and has automated end-of-roll and splice detection sensors. The drive direction is reversible which provides flexibility in positioning preprinted forms. The Unwind 52 works in-line, feeding directly into printers, or offline, feeding inserters, other Stralfors solutions and finishing equipment.
Benefits of the Lasermax Unwind 52:
• Quick loading and changing of rolls
• Positive locking feature, no operator adjustment
• No exposed “pinch points” for maximum safety
• Ability to feed directly into inserters
• Center-shaft driven—no surface contact with forms
• Low profile allows unobstructed view of print operation
• Compatible with pressure sensitive labels
Standard Features Include:
• Microprocessor controlled
• LCD Operator Panel
• UL approved number EMRT—Data Processing Equipment
• Onboard diagnostics
• Automatic splice detector
• Compatible with multiple core sizes
• Unwind 52 feeds paper up to 260 ft/min
• Unwind 52CDC feeds paper up to 500 ft/min
